Measurement Functions |
Measurement Functions |
|
Frequency, Burst Frequency, Period, Ratio f1/f2, Pulse Width, Duty Factor, Totalize A |
|
Frequency A, C |
Input A: |
10 Hz to 300 MHz |
Input C (Optional Input Pre-Scaler): |
PM9624: 100 MHz to 3.0 GHz |
|
PM9638: 300 MHz to 8.0 GHz |
Resolution: |
10 digits/s measurement time |
|
Burst Frequency A |
Frequency range: |
100 Hz to 80 MHz |
PRF range: |
up to 1 MHz |
Burst duration: |
0.5 μ to 1.5 s,min. 3 cycles in burst |
|
Burst Frequency C |
Frequency range: |
100 MHz to 8GHz |
PRF range: |
up to 1 MHz |
Burst duration: |
0.5 μs to 1.5 s |
|
Period A |
Range: |
3.3 ns to 100 ms |
Resolution: |
10 digits/s measurement time |
|
Ratio A/E, C/A |
Range: |
10 -9 to 10 9 |
Frequency range: |
Input A: 10 Hz to 300 MHz (prescaling factor 4) |
|
Input E: 10 Hz to 80 MHz |
|
Input C: See input C frequency range |
|
Pulse Width A |
Range: |
6 ns to 10ms |
Frequency range: |
50 Hz to 60 MHz |
Voltage range: |
100 mV p-p to 70 V p-p |
|
Duty Factor A |
Range: |
0 to 1 |
Frequency range: |
50 Hz to 60 MHz |
Voltage range: |
100 mV p-p to 70 V p-p |
|
Totalize A |
|
Event Counting on A with manual start and stop |
Range: |
0 to 10 14 |
Frequency Range: |
0 to 100 MHz |
|
Optional TimeBase |
Standard: PM6685/-1- (Non -Retrofit) |
Calibration adjustment tolerance* * * at +23ºC ± 3ºC: |
< 1 x 10 -6 |
Uncertainty due to: |
|
Aging /24 hr: |
N/A* |
Aging /month: |
< 5 x 10 -7 |
Aging /year: |
< 5 x 10 -6 |
Temperature Stability (reference temp at +23ºC): |
0-50ºC: < 1 x 10 -5 |
|
20ºC -26ºC: 3 x 10 -6 |
Line voltage variation of ±10%: |
< 1 x 10 -8 |
Power On Stability: |
Not Specified |
Total Uncertainty* * * * at 2σ (95%) confidence |
|
interval and at 23ºC ± 3ºC: |
After 1 Year Cal interval < 7 x 10 -6 |
|
After 2 Year Cal interval < 1.2 x 10 -5 |
Total Uncertainty* * * * at 2σ (95%) confidence |
|
interval and at 0-50ºC: |
After 1 Year Cal interval < 1.2 x 10 -5 |
|
After 2 Year Cal interval < 1.5 x 10 -5 |
|
OCXO: PM6685/-5- (PM9691) |
Calibration adjustment tolerance* * * at +23ºC ± 3ºC: |
< 2 x 10 -8 |
Uncertainty due to: |
|
Aging /24 hr: |
< 5 x 10 -10 * * |
Aging /month: |
< 1 x 10 -8 |
Aging /year: |
< 7.5 x 10 -8 |
Temperature Stability (reference temp at +23ºC): |
0-50ºC: < 5 x 10 -9 |
|
20ºC -26ºC < 6 x 10 -10 (typical values) |
Line Voltage variation of ±10%: |
< 5 x 10 -10 |
Power-on stability: |
1 x 10 -7 Deviation versus final value |
|
after 24 hr on time, after a warm-up time of: 15 min |
Total Uncertainty* * * * at 2σ (95%) confidence |
|
interval and at 23ºC ± 3ºC: |
After 1 Year Cal interval: < 9 x 10 -8 |
|
After 2 Year Cal interval: < 1.5 x 10 -7 |
Total Uncertainty* * * * at 2σ (95%) confidence |
|
interval and at 0-50ºC: |
After 1 Year Cal interval: < 1 x 10 -8 |
|
After 2 Year Cal interval: < 2 x 10 -7 |
|
OCXO: PM6685/-6- (PM9692) |
Calibration adjustment tolerance* * * at +23ºC ± 3ºC: |
< 5 x 10 -9 |
Uncertainty due to: |
|
Aging /24 hr: |
< 1 x 10 -10 * * |
Aging /month: |
< 3 x 10 -9 |
Aging /year: |
< 2 x 10 -8 |
Temperature Stability (reference temp at +23ºC): |
0-50ºC: < 2.5 x 10 -9 |
|
20ºC -26ºC: < 4 x 10 -10 (typical values) |
Line Voltage variation of ±10%: |
< 5 x 10 -10 |
Short term stability: |
(root Allan Variance) |
|
T = 1 s: 5 x 10 -11 |
|
T = 10 s: 5 x 10 -12 |
Power-on stability: |
5 x 10 -9 Deviation versus final value |
|
after 24 hr on time, after a warm-up time of: 10 min |
Total Uncertainty* * * * at 2σ (95%) confidence |
|
interval and at 23ºC ± 3ºC: |
After 1 Year Cal interval: < 2.5 x 10 -8 |
|
After 2 Year Cal interval: < 5 x 10 -8 |
Total Uncertainty* * * * at 2σ (95%) confidence |
|
interval and at 0-50ºC: |
After 1 Year Cal interval: < 2.5 x 10 -8 |
|
After 2 Year Cal interval: < 5 x 10 -8 |
|
* N/A: Not discernible, neglectable versus 1°C temperature variation. * * After 14 days continuous operation * * * Calibration Adjustment Tolerance: Is the maximal tolerated deviation from the true 10MHz frequency after a calibration. When the reference frequency does not exceed the tolerance limits at the moment of calibration, an adjustment is not needed. * * * * Total uncertainty: Is the total possible deviation from the true 10MHz value under influence of frequency drift due to aging and ambient temperature variations versus the reference temperature. The operating temperature range and the calibration interval are part of this specification.
Input and Output Specifications |
Input A |
Frequency Range: |
10 Hz to 300 MHz |
Coupling: |
AC |
Impedance: |
1 MΩ//25pF or 50Ω, VSWR < 2:1 |
Sensitivity (SineWave): |
10 mV rms, 10 Hz to 50 MHz |
|
15 mV, 50 MHz to 100 MHz |
|
20 mV, 100 MHz to 150 MHz |
|
30 mV, 150 MHz to 200 MHz |
|
50 mV, 200 MHz to 300 MHz |
Pulse: |
50 mV p-p, 3 ns minimum pulse width |
Dynamic Range: |
30 mV p-p to 70V p-p |
|
Manual Trigger |
Sensitivity Range: |
|
|
10 mV rms to 10 Vrms, variable in 3 dB steps, indicated on bar graph |
Trigger Level: |
Selectable for optimum triggering on |
|
waveforms with duty factors of <0.25, 0.25 to 0.75 and |
|
0.75 |
Trigger Slope: |
Positive or Negative |
|
Auto Trigger |
|
Automatic setting of input signal conditioning circuits for |
|
optimum triggering on different amplitudes and |
|
waveforms |
Frequency: |
Minimum 50 Hz |
Sensitivity Range: |
10 mV rms to 25V rms |
|
Signal Monitor |
|
A bar graph displays actual input signal level in 3 dB |
|
steps, 10 mV rms to 10 Vrms |
|
Low Pass Filter |
|
100 kHz nominal 3 dB point |
|
Minimum 40 dB attenuation at 1 MHz |
|
Damage Level |
1 MΩ Impedance: |
350V (DC + AC peak) at DC to 440 Hz, falling to 12 Vrms |
|
at 1 MHz and above |
50 Ω Impedance: |
12 V rms |
|
Auxiliary Functions |
External Arming/External Gate |
|
External signal on input E can be used to inhibit start |
|
and/or stop triggering |
|
Stop arming is not applicable to Pulse Width and Duty |
|
Factor measuring modes |
|
Start Arming Delay |
|
OFF or 200 ns to 5s in 100 ns steps |
|
Nulling/Frequency Offset |
|
Nulling enables measurements to be displayed relative to |
|
a previously measured value or any value entered in via |
|
front panel keys |
|
Optional Pre-Scalers |
Input C (PM 9624) |
Frequency Range: |
100 MHz to 3.0 GHz |
Pre-Scaler Factor: |
64 |
Sensitivity: |
20 mV rms to 12V rms, 100 to 300 MHz |
|
10 mV rms to 12V rms, 0.3 GHz to 2.5 GHz |
|
20 mV rms to 12V rms, 2.5 GHz to 2.7 GHz |
|
100 mV rms to 12V rms, 2.7 GHz to 3.0 GHz |
Amplitude Modulation: |
DC to 0.1 MHz: Up to 94% depth |
|
0.1 to 6 MHz: Up to 85% depth |
|
Minimum signal must exceed Input Sensitivity |
Impedance: |
50Ω nominal, ac coupled, VSWR < 2.5:1 |
Damage Level: |
12V rms pin diode protected |
Connector: |
Type N Female |
|
Input C (PM9638) |
Frequency Range: |
3 MHz to 8 MHz |
Prescalar Factor: |
256 |
Operating Input Voltage Range: |
300...500 MHz: -21...+30 dBm |
|
0.5...3 GHz: -27...+30 dBm |
|
3.0...4.5 GHz: -21...+30 dBm |
|
4.5...6.0 GHz: -15...+30 dBm |
|
6.0...8.0 GHz: -9...+30 dBm |
Impedance: |
500 Ω nominal, AC coupled, VSWR <2:1 |
Max Input Voltage Without Damage: |
7 V RMS, pin diode protected |
Damage Connector: |
Type N female |
|
External Reference |
Input D |
|
The use of external reference is indicated on the front |
|
panel display |
Input Frequency: |
10 MHz |
|
with optional reference multiplier PM 9697 |
Voltage Range: |
200 mV rms to 10V rms |
Impedance: |
Approximately 1 kΩ, ac coupled |
|
Input E |
|
Used in ratio A/E and external arming / gating modes |
Frequency Range: |
DC to 80 MHz |
Pulse Width: |
6 ns minimum |
Slew Rate: |
2V/μs minimum |
Trigger Level: |
TTL level, 1.4 V nominal |
Trigger Slope: |
Positive or Negative |
Impedance: |
Approximately 2 kΩ, dc coupled |
Damage Level: |
±25V peak |
|
Reference Output G |
Frequency: |
10 MHz, Sine Wave |
Output: |
0.5 V rms into 50Ω load, > 0.7 V rms into hi |
|
impedance load, Ac coupled |
|
Options (Battery Unit PM 9623) |
Battery Unit (Option PM 9623) |
|
The PM 9623 is a rechargeable battery unit for mounting |
|
inside the counter |
|
Battery Type |
|
Battery Capacity |
|
at 25ºC |
Standby Mode: |
Typically 20 hours with Oven Time Base |
Operating Mode: |
|
|
Typically 3 hours without options, 2.5 |
|
hours with Oven Time Base, and 2 hours with Oven Time Base and Input C |
|
Recharge Time |
|
Typically 8 hours in standby mode |
Battery Protection: |
Overcharge and deep discharge protection |
External DC: |
12V to 24V via socket on rear panel (16V |
|
to 24V to charge internal battery) |
Line Failure Protection: |
Counter automatically switches |
|
to internal battery or external DC when the line voltage falls below 90V AC |
|
Temperature |
Operating: |
0ºC to +40ºC |
Storage: |
-40ºC to +50ºC |
|
Weight |
|
